10.1 inch EJ101IA-01B Innolux LCD Panel with 216.96×135.6 mm

Name: 101 inch EJ101IA01B Innolux LCD Panel with 216961356 mm
Brand: Innolux
Price: 1 USD

Brand Name : Innolux

Model Number : EJ101IA-01B

Certification : ISO9001

Place of Origin : KOREA

MOQ : 1

Payment Terms : T/T, Paypal, Western Union, MoneyGram

Supply Ability : 500PCS/DAY

Delivery Time : 2-3 working days after payment confirmation

Packaging Details : Antistatic bag, Bubble Bag, Foam Box and Carton Box.

Panel Size : 10.1 inch

Resolution : 1280(RGB)×800 , WXGA

Display Mode : IPS, Normally Black, Transmissive

Signal Interface : LVDS (1 ch, 8-bit) , 40 pins

Contact Now

10.1 inch EJ101IA-01B Innolux LCD Panel with 216.96×135.6 mm

Products Information:

Panel Size :

10.1 inch

Dot Resolution :

1280(RGB)×800 (WXGA)

Pixel Configuration :

RGB Vertical Stripe

Pixel Density :

149 PPI

Aspect Ratio :

16:10 (H:V)

Form Factor :

Flat Rectangle Display

Dot Pitch :

0.0565×0.1695 mm (H×V)

Pixel Pitch :

0.1695×0.1695 mm (H×V)

Weight :

169.59g

Surface :

Hard coating

Active Area :

216.96×135.6 mm (H×V)

Outline Dimension :

229.46×149.1 mm (H×V)

Outline Depth :

2.4/4.31 (Typ./Max.) mm

Holes & Brackets :

Without

Landscape or Portrait :

Landscape type

Touch Panel :

Without

Display Mode :

IPS, Normally Black, Transmissive

Brightness :

350 cd/m² (Typ.)

Contrast Ratio :

800 : 1 (Typ.) (Transmissive)

Display Color :

16.7M (8-bit)

Response Time :

10/15 (Typ.)(Tr/Td)

Viewing Angle :

85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)

Viewing Direction :

Symmetry

White color Chromaticity :

Wx:0.310; Wy:0.330

White Variation :

1.33/1.43 (Typ./Max.)(13 points)

Sunlight Readable :

FAQ
Q1: How do we place an order?
A1: Please kindly send us an email specifying the item No., replacements, quantity, other specifications for the Hard disk to place an order.
Q2: How do we make the payment?
A2: We accept T/T, Western Union, MoneyGram, Paypal.
Q3: What's the delivery time?
A3: The delivery time is normally 1-3 working days after payment.
Q4: How would the goods be shipped?
A4: We ship via DHL, UPS, TNT and others.

Packaging & Delivery
Packaging: Safety Package For all of our LCD Screen Panel Replacements.
Details: 1. Antistatic bag
2. Layers of cartons
3. Foam Box
4. Carton Box.

Here comes our other LCD panels stock for your easy reference:
Pls contact to us for more stock information: salespm@nselectronic.com.hk

Panel Model	Brand	Size	Resolution
AE060RN01	Innolux	6.0"	800×600
F050A12-601	Innolux	5.0"	480×854
85C02502-Y21	Innolux	2.5"	320×240
V260B2-P03 Rev.C2	Innolux	26.0"	1366×768
G070YG1-P01	Innolux	7.0"	800×480
F03215-01Z	Innolux	3.2"	360×480
F0352A-01U	Innolux	3.5"	320×480
F07020-01D	Innolux	7.0"	480×234

EJ101IA-01B Picture
