New and original G260J1-L05 CHIMEI INNOLUX a-Si TFT-LCD ,25.5 inch, 1920×1200 for Industrial Application
G260J1-L05 Basic Information
| Panel Model | G260J1-L05 |
| Panel Brand | CHIMEI INNOLUX |
| Descrition | a-Si TFT-LCD ,25.5 inch, 1920×1200 |
| Panel Type | a-Si TFT-LCD |
| Operating Temperature | 0 ~ 50 °C |
| Storage Temperature | -20 ~ 60 °C |
| Remarks | TCO’03 compliance |
Packaging & Delivery
Packaging Details: Safe & Professional packing or as requirement for the LCD Screen replacements.
Delivery Detail: 2-3 days after receipt of payment
Payment terms: We accept T/T, PayPal, Western Union and others.
G260J1-L05 Mechanical Features
| Dot Resolution | 1920(RGB)×1200 (WUXGA) |
| Pixel Configuration | RGB Vertical Stripe |
| Pixel Density | 88 PPI |
| Aspect Ratio | 16:10 (H:V) |
| Form Factor | Flat Rectangle Display |
| Dot Pitch | 0.0955×0.2865 mm (H×V) |
| Pixel Pitch | 0.2865×0.2865 mm (H×V) |
| Weight | 3.45Kgs (Max.) |
| Surface | Antiglare (Haze 25%), Hard coating (3H) |
| Active Area | 550.08×343.8 mm (H×V) |
| Bezel Area | 554.1×347.8 mm (H×V) |
| Outline Dimension | 582×375.6 mm (H×V) |
| Outline Depth | 41.5±0.5 mm |
| Landscape or Portrait | Landscape type |
| Touch Panel | Without |
Quality Control:
1Visual Inspection
Make sure No damage, No Scratches, No dusty, No light leakage.
2Function Inspection
Make sure all functions are 100% tested ok
G260J1-L05 Optical Features
| Display Mode | Super MVA, Normally Black, Transmissive |
| Brightness | 350 cd/m² (Typ.) |
| Contrast Ratio | 1500 : 1 (Typ.) (Transmissive) |
| Display Color | 16.7M (8-bit) |
| Color Gamut | 92% NTSC (CIE1931) |
| Response Time | 15/5 (Typ.)(Tr/Td) |
| Viewing Angle | 88/88/88/88 (Typ.)(CR≥10) (L/R/U/D) |
| Viewing Direction | Symmetry |
| White color Chromaticity | Wx:0.313; Wy:0.329 |
| White Variation | 1.40/1.50 (Typ./Max.)(13 points) |
| Sunlight Readable | N |
Packing& Shipping:
Fast & Cheap Delivery: We have big discount from forwarder (Long Contract).
Guarantee:
(1) All items will be strictly tested and shipped with strong package.
(2) We have 3~6months warranty for every item, depend on the different item.
(3) We will do our best to solve any possible problem for your after sale. Please contact with us.
G260J1-L05 Electronics Feature
| Vertical Frequency | 60Hz |
| Reverse Scan | No |
Below are our other LCD panels stock for your easy reference:
| Panel Model | Brand | Size | Resolution |
| M280HKJ-P02 | Innolux | 28.0" | 1920×1080 |
| PG047IC-01B | Innolux | 4.7" | 720×1280 |
| PP037IC-01B | Innolux | 3.7" | 480×800 |
| V650DK1-QS2 | Innolux | 65" | 3840×2160 |
| MT190AW02 V.W CELL | Innolux | 19.0" | 1440×900 |
| V580HJ1-PD6 | Innolux | 58" | 1920×1080 |
| C02706-01Z | Innolux | 2.7" | 320×240 |
| V650HP1-PS1 | Innolux | 65" | 1920×1080 |
We also have other industrial LCD panels, pls contact to us for the further information
G260J1-L05pictures
